Whether to use steam condenser or chimney for brewhouse is a general topic that usually being discussed about in building brewing projects. Here we’d like to share some of our experiences and ideas about how to choose between this two options for your brewing facilities, hope to be any helpful for your decision making. Any questions or other information interested just feel free to contact us please, we shall be honored and more than happy to do what we can to help, Cheers!


Main advantages of steam condenser:
1) Energy Efficiency: Steam condensers capture and recycle steam generated during the brewing process, allowing breweries to reuse energy that would otherwise be lost. This can lead to significant energy savings over time.

2) Water Conservation: By condensing steam back into water, steam condensers help conserve water resources, as the condensed water can be reused in the brewing process or for other purposes.

3) Environmental Impact: Steam condensers minimize the release of steam, heat, and humidity into the surrounding environment, reducing the brewery's environmental footprint and contributing to a more sustainable operation.

4) Regulatory Compliance: In many jurisdictions, regulations require breweries to control steam emissions and minimize environmental impact. Steam condensers help breweries meet these regulatory requirements more effectively than chimneys.

5) Improved Working Conditions: Steam condensers help maintain a comfortable working environment for brewery staff by reducing heat and humidity levels in the brewhouse. This can improve worker productivity and morale.

6) Space Efficiency: Steam condensers are typically compact and can be integrated into existing brewing equipment or facilities without requiring additional space. This makes them a practical choice for breweries with limited space or ventilation options.


A “chimney” in brewhouse typically refers to a vent or exhaust system used to release steam generated during the brewing process. Instead of utilizing a steam condenser to capture and condense steam into water, some craft breweries would opt for a chimney to directly vent steam outside the brewing facility.


The chimney serves as a means of dissipating excess steam and heat from the brewhouse, preventing the buildup of humidity and maintaining a comfortable working environment for brewery staff. Additionally, it helps to remove unwanted odors and airborne contaminants that may be present during brewing.

500L brewery project with chimney in Switzerland.

While steam condensers are effective at recovering and reusing steam energy, some breweries may prefer the simplicity and cost-effectiveness of a chimney system, especially for smaller-scale operations or facilities with adequate ventilation. However, the choice between a chimney and a steam condenser ultimately depends on factors such as space, budget, energy efficiency goals, and regulatory requirements.
